TYRE PRESSURE GAUGE WITH ADAPTERS (Fig. 1 / Item G)
Working pressure in bar: 0-8
Range of applications:
The tyre pressure gauge allows you to inate car tyres easily and exactly.
Use the pressure gauge to check the tyre pressure. If the tyre pressure is too high,
you can reduce the pressure with the integrated relief valve (7).
The tyre pressure gauge comes with a valve adapter for car tyre valves.
IMPORTANT! The pressure gauge is not calibrated!
Please check the tyre pressure immediately after lling with air, for example at your
lling station.
ON/OFF SWITCH (Fig. 1 / Item 2)
To start the compressor, the switch has to be in position "I".
To stop the compressor, the switch has to be in position "0".
ADAPTER SET INSTRUCTIONS
For information on the correct use of the adapters for the various valves, please
refer to the following overview.
Fitting the accessory
Attach the compressed air tools to the tyre pressure gauge (G) which has to be
connected to the pressure hose (5).
Using the equipment as a blow-out pistol (Fig. 1 / Item D)
To use the tyre pressure gauge (G) as a blow-out pistol you must rst unscrew and
remove the hose with the valve adapter for car tyres. Now the Extension nozzle (D)
can be screwed to the tyre pressure gauge (G).
Range of applications:
For cleaning and blowing out hollow spaces or hard-to-reach areas, as well as for
cleaning soiled equipment. The variable trigger lever allows an exact dosage of
compressed air.
Ball needle (Fig. 1&4 / Item F)
Range of applications: For inating balls. The ball needle (F) can be used to inate a
variety of different balls.
TIP: To avoid damaging the valve, moisten the needle slightly before inserting
it.
AUS
AIR FORCE Attachment and operation
AFTER SALES SUPPORT
15
1300 855 831
support@scheppach.com.au
MODEL: AIR FORCE PRODUCT CODE: 56102 02/2018
