2. Layout (Fig. 1)
1 Transport handle
2 ON/OFF switch
3 Compressor housing
4 Quick-lock coupling
5 Pressure hose
6 Power cord with power plug
7 Integrated relief valve
Accessory
A Universal adapter,for valves with internal Ø of approx. 6 mm
B Universal adapter,for valves with internal Ø of approx. 9 mm
C Cap for H, J, K
D Extension nozzle
E Valve adapter, e.g. for cycle tyre valves
F Ball needle
G Tyre pressure gauge
H Adapter for deator valves
J Adapter for screw valves, e.g. on inatable dinghies
K Universal adapter,for valves with internal Ø of approx. 8 mm
3. Scope of delivery
• Open the packaging and remove the device carefully.
• Remove the packaging material as well as the packaging and transport bracing
(if available).
• Check that the delivery is complete.
• Check the device and accessory parts for transport damage.
• If possible, store the packaging until the warranty period has expired.
m Attention!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic bags, lm and small parts!
There is a risk of swallowing and suffocation!
