Valve adapter (Fig. 1 / Item E)
Range of applications: For Dunlop bicycle tyre valves. This Dunlop valve adapter is
designed for inating cycle tyres. For inating car tyres, please see the tyre pressure
gauge with adapters.
Universal adapter, for valves with internal Ø of approx. 8 mm (Fig. 1 / Item K)
Range of applications: For all valves with an internal diameter of 8 mm or more.
You can use this adapter to inate airbeds, pools or boats.
TIP: Insert the adapter (K) into the valve as shown in Figure 5.
Attention! The valve cap must be opened a little by being pressed together slightly.
Adapter for screw valves (Fig. 1 / Item J)
Range of applications: For screw valves.
This adapter can be used for all conventional boats, kayaks and other large items
such as pools, which are tted with a screw valve.
Vent adapter (Fig. 1 / Item H)
Range of applications: For deation valves
You can nd a deation valve combined with other valves (standard valve, screw
valve, etc.) on many large articles such as an inatable mattress.
Conical universal adapter (Fig. 1 / Item A&B)
Range of applications: For inating airbeds and similar.
8. Technical data
Mains connection 220 - 240 V ~ 50 Hz
Motor rating W 110 0
Operating mode S3 15%*
Compressor speed 3750 min
-1
Operating pressure approx. 8 bar
Theoretical intake capacity (l/min) approx. 180
Sound power level L
WA
97 dB(A)
Uncertainty K
WA
1.93 dB
Protection type IP20
Weight of the unit in kg approx. 5.3
Max. Altitude (above mean sea level) 1000 m
The noise emission values were measured in accordance with EN ISO 3744.
AUS
Attachment and operation / Technical data AIR FORCE
16
AFTER SALES SUPPORT
support@scheppach.com.au
1300 855 831
MODEL: AIR FORCE PRODUCT CODE: 56102 02/2018
