* S3 Intermittent periodic duty
A sequence of identical duty cycles, made up with a time of operation at constant
load and a time at rest. When at rest, the motor is not fed.
Identical duty cycles with a period at load followed by a period at no load. Run-
ning time 10 minutes; duty cycle is 15% of the running time.
Wear hearing protection
The effects of noise can cause a loss of hearing.
9. Electrical connection
The electrical motor installed is connected and ready for operation. The connection
complies with the applicable Australian standards.
The customer‘s mains connection as well as the extension cable used must also
comply with these regulations.
Important information
In the event of an overloading the motor will switch itself off. After a cool-down
period (time varies) the motor can be switched back on again.
Damaged electrical connection cable
The insulation on electrical connection cables is often damaged.
This may have the following causes:
• Passage points, where connection cables are passed through windows or
doors.
• Kinks where the connection cable has been improperly fastened or routed.
• Places where the connection cables have been cut due to being driven over.
• Insulation damage due to being ripped out of the wall outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not be used and are
life-threatening due to the insulation damage. Check the electrical connection
cables for damage regularly. Make sure that the connection cable does not hang on
the power network during the inspection. Electrical connection cables must comply
with the applicable Australian standards and must be correctly marked. Only use
connection cables with the marking „H05VV-F“. Replacement cables can only be
tted by an approved and certied electritian. If you are in any doubt please contact
the help line at the foot of this page.
AC motor
• The mains voltage must be 220 - 240 V~
• Extension cables up to 25 m long must have a cross-section of 1.5 mm
2
.
Connections and repairs of electrical equipment may only be carried out by an
electrician.
AUS
AIR FORCE Technical data / Electrical connection
AFTER SALES SUPPORT
17
1300 855 831
support@scheppach.com.au
MODEL: AIR FORCE PRODUCT CODE: 56102 02/2018
