Installation and Operations Guide
|
MS/TP Microset II
40
LTBT-MSTPMS2IOG Rev. 02 © Honeywell
MS/TP Microset II objects
Object properties
Device object properties
Object
(instance range)
Remarks
AI-(0) AI-0 is the MS/TP Microset II internal sensor analog input object.
AV-(90–107) RESERVED AVs for Alerton legacy Microset behavior.
AV-(0-47) General use AVs.
BV-(0-47) General use BVs. BV-40 supports the priority-array property.
BV-40 is typically used by Alerton DDC applications to receive scheduled occupancy
commands from a global controller. The priority array allows a BACnet user to override
the occupancy command. When in Occupancy mode with an internal schedule enabled,
internal schedule commands are written to BV-40 priority 16, therefore DDC
applications that use BV-40 can easily use either internal or external scheduling.
BV-(99) Disable unoccupied setpoint deadband
File (254) Provides information about the ROC file.
Program 254 Firmware program. Entry into boot loader requires writing password to property
ALERBP_DOWNLOAD_PASSWORD.
File 240 Legacy method of setting device instance. Has special security feature
File 254 File object used to do firmware download. Has special semantics.
File 260 AI-Linearization data. Only writable by halting associated program object.
Program 260 Allows access to AI-linearization data when halted. Halting requires writing password
to property ALERBP_DOWNLOAD_PASSWORD.
Property Access Notes
Object Identifier R
Object Name R/W
Object Type R
System Status R OPERATIONAL
Vendor Name R “Alerton”
Vendor Identifier R 18
Model Name R VLC-MS-2100H-MSTP
Firmware Revision R (comes from boot loader) initially “RL 5.00 (build x)”
Application Software Version R “5.00 (build y)” or similar
Location R/W
Description R/W
Protocol Version R 1
Protocol Revision R 4
