Installation and Operations Guide
|
MS/TP Microset II
8
LTBT-MSTPMS2IOG Rev. 02 © Honeywell
Mounting
The MS/TP Microset II is designed to be wall-mounted indoors, with dimensions
ideal for mounting to a single-gang electrical box. See Fig. 3 on p. 10.
Mount in a clean, dry location away from windows, air ducts, and other places
where environmental factors may affect temperature and humidity readings.
Note If you mount the MS/TP Microset II on the interior of an outside wall,
thoroughly insulate so air behind the sensor doesn’t affect the sensor reading.
To meet requirements of the Americans with Disabilities Act, mount no higher
than 48" from the floor and with a minimum clear floor space of 30" X 48" (760
X 1220 mm). See Figure 1.
Figure 1 Mounting guidelines for compliance with Americans with Disabilities
Act (ADA).
