Mode IDs
M1—Office, no fan, occupied
M2—Office, no fan, unoccupied
M3—Office, no fan, ON/OFF
M4—Office, fan, occupied
M5—Office, fan, unoccupied
M6—Hotel, no fan, rented
M7—Hotel, no fan, vacant
M8—Hotel, fan, rented
M9—Hotel, fan, vacant
See Table 5 on page 22 for more
information.
Field Service Codes
Code Data point Meaning
UC. AV-95 Unoccupied cooling setpoint
UH. AV-96 Unoccupied heating setpoint
CO. AV-93 Cooling offset
HO. AV-94 Heating offset
CS. AV-99 Occupied cooling setpoint
HS. AV-100 Occupied heating setpoint
AL. AV-97 Override limit
rO AV-108 Room temperature offset
hO AV-109 Space humidity offset
HI. AV-91 Setpoint high limit
LO. AV-92 Setpoint low limit
SP. AV-90 Occupant-selected space temperature setpoint
Quick reference (continued)
