Enabling operating modes
Combinations of values for BVs 64, 65, 80, and 81 control operating modes. In
each mode, BV-67 (a read-only point) reports occupied/unoccupied status. Use
this data point in DDC as a flag to control occupied and unoccupied operating
sequences.
Table 5 lists data point settings for the various operating modes and indicates the
action of BV-67 in each mode. See Table 8 on page 43 for further detail.
Office modes
Office modes are typically used in commercial use environments.
M1—Office, No Fan, Occupied
Set BV-64 ON and BV-65, BV-80, and BV-81 OFF. The LCD displays the
occupant-selected space temperature setpoint (AV-90). The unit controls to
occupied setpoints.
Table 5 Data point settings for MS/TP Microset II operating modes, with BV-67 status.
Mode Description BV-64
Occupied
BV-65
ON/OFF
BV-80
Fan-control
BV-81
Hotel
BV-67 (read only)
occupied/unoccupied status
M1 Office, no
fan, occupied
ON OFF OFF OFF ON
M2 Office, no
fan,
unoccupied
OFF OFF OFF OFF OFF unless after-hours timer (AV-98) is
non-zero.
M3 Office, no
fan, ON/OFF
ON ON OFF OFF Right
UP/DOWN buttons control BV-67 to match
occupant selected ON/OFF status.
UP turns
BV-67 ON,
DOWN turns it OFF.
M4 Office, fan,
occupied
ON
ON
a
a. The Microset turns BV-65 ON in these modes.
ON OFF ON unless the fan is OFF (BVs 72-74 OFF), then
BV-67 is OFF.
M5 Office, fan,
unoccupied
OFF
ON
a
ON OFF OFF unless after-hours timer (AV-98) is
non-zero.
M6 Hotel, no fan,
rented
ON
ON
a
OFF ON Right UP/DOWN buttons control BV-67 to match
occupant selected ON/OFF status.
UP turns
BV-67 ON,
DOWN turns it OFF.
M7 Hotel, no fan,
vacant
OFF
ON
a
OFF ON OFF unless housekeeping timer (AV-98) is
non-zero.
M8 Hotel, FC,
Rented
ON
ON
a
ON ON ON unless the fan is OFF (BVs 72-74 OFF), then
BV-67 is OFF.
M9 Hotel, FC,
Vacant
OFF
ON
a
ON ON OFF unless housekeeping timer (AV-98) is
non-zero.
