16
TECHNICAL SPECIFICATIONS
Interface: iO2 EXPRESS 24-bit audio / MIDI interface
Features: Stereo, 24-bit inputs/outputs
Sample-rate adjustable up to 48 kHz
Separate gain knob and mic/line / guitar switch for each input
All balanced inputs and outputs
Stereo 1/4" headphone jack
MIDI I/O
Audio I/O: Mic inputs:
SNR: 95dB (A-weighted) minimum – 97dB typical
THD+N: 0.007% maximum – 0.005% typical
Frequency Response: ±0.35dB typical
1/4" guitar/line inputs:
SNR: 94dB (A-weighted) minimum – 96dB typical
THD+N: 0.05% maximum – 0.034% typical
Frequency Response: ±1.2dB typical
Analog outputs:
SNR: 95dB (A-weighted) minimum – 97dB typical
THD+N: 0.007% maximum – 0.005% typical
Frequency Response: ±0.35dB typical
Power: USB bus power
Dimensions: 6.1" x 4.9" x 2" / 155 mm x 124mm x 51 mm
Weight (net): .85 lbs / 0.39 kg
* Specifications are subject to change without notice.
7-51-0311-A
