Alesis QS Series Keyboards Service Manual V1.00 66 11/19/06
DELAY SEND 1:
# Parameter name Send Func Page Pot Offset Limit bits bit address
25. Send 1 delay type 0 4 0 0 0 2 2 13:3-13:2
26. Send 1 delay input balance 0 4 0 2 -99 198 8 14:3-13:4
27. Send 1 delay input 2 0 4 0 1 0 5 3 36:2-36:0
If 25=0 (mono delay):
28. Send 1 delay 10ms 0 4 1 1 0 79 7 15:2-14:4
29. Send 1 delay 1ms 0 4 1 2 0 9 4 15:6-15:3
30. Spare 6 16:4-15:7
31. Spare 4 17:0-16:5
32. Send 1 delay feedback 0 4 1 3 0 99 7 17:7-17:1
33. Spare 7 18:6-18:0
34. Send 1 delay mix 0 5 0 3 0 99 7 19:5-18:7
If 25=1 (stereo delay):
28. Send 1 left delay 10ms 0 4 1 1 0 39 7 15:2-14:4
29. Send 1 left delay 1ms 0 4 1 2 0 9 4 15:6-15:3
30. Send 1 right delay 10ms 0 4 2 1 0 39 6 16:4-15:7
31. Send 1 right delay 1ms 0 4 2 2 0 9 4 16:8-16:5
32. Send 1 left delay feedback 0 4 1 3 0 99 7 17:7-17:1
33. Send 1 right delay feedback 0 4 2 3 0 99 7 18:6-18:0
34. Send 1 delay mix 0 5 0 3 0 99 7 19:5-18:7
If 25=2 (ping-pong delay):
28. Send 1 delay 10ms 0 4 1 1 0 39 7 15:2-14:4
29. Send 1 delay 1ms 0 4 1 2 0 9 4 15:6-15:3
30. Spare 6 16:4-15:7
31. Spare 4 17:0-16:5
32. Send 1 delay feedback 0 4 1 3 0 99 7 17:7-17:1
33. Spare 7 18:6-18:0
34. Send 1 delay mix 0 5 0 3 0 99 7 19:5-18:7
REVERB SEND 1:
35. Reverb type 0 3 1 0 0 6 4 20:1-19:6
36. Send 1 reverb input 1 0 3 0 0 0 1 1 20:2
37. Send 1 reverb input 2 0 3 0 1 0 5 3 31:0-30:6
38. Send 1 reverb balance 0 3 0 2 -99 198 8 21:4-20:5
39. Send 1 reverb input level 0 3 0 3 0 99 7 22:3-21:5
40. Send 1 reverb prdly 10ms 0 3 1 1 0 29 5 23:0-22:4
41. Send 1 reverb prdly 1ms 0 3 1 2 0 9 4 23:4-23:1
42. Send 1 reverb inut premix 0 3 1 3 -99 198 8 24:4-23:5
43. Send 1 reverb input filter 0 3 2 0 0 99 7 25:3-24:5
44. Send 1 reverb decay 0 3 2 1 0 99 7 26:2-25:4
45. Send 1 reverb diffusion 0 3 3 2 0 99 7 27:1-26:3
46. Send 1 reverb density 0 3 3 0 0 99 7 28:0-27:2
47. Send 1 reverb low decay 0 3 2 2 0 99 7 28:7-28:1
48. Send 1 reverb high decay 0 3 2 3 0 99 7 29:6-29:0
49. Send 1 reverb mix 0 5 1 0 0 99 7 30:5-29:7
OVERDRIVE SEND 1:
50. Send 1 overdrive type 0 6 0 0 0 1 1 44:5
52. Send 1 overdrive balance 0 6 1 2 -99 198 8 48:2-47:3
63. Send 1 overdrive threshold 0 6 0 2 0 99 7 50:4-49:6
64. Send 1 overdrive brightness 0 6 1 0 0 99 7 49:1-48:3
65. Send 1 overdrive mix 0 6 0 0 0 99 7 31:7-31:1

Alesis QS Series Specifications

General

Multitimbral	16 parts
Oscillators	Sample-based
Effects	Reverb, Chorus, Delay, EQ, Distortion
Display	LCD
MIDI	In, Out, Thru
Memory	User Programs
Outputs	Stereo
Weight	11 kg
