Alesis QS Series Keyboards Service Manual V1.00 67 11/19/06
EQUALIZER:
# Parameter name Send Func Page Pot Offset Limit bits bit address
61. Low EQ Frequency x 6 0 0 0 5 3 44:0-43:6
62. Low EQ Gain x 6 0 1 0 12 4 45:1-44:6
63. Hi EQ Frequency x 6 0 2 0 7 3 45:7-45:5
64. Hi EQ Gain x 6 0 3 0 9 4 46:7-46:4
MODULATION:
82. MIDImod source 1 x 1 0 0 0 10 4 59:1-58:6
83. MIDImod destination 1 x 1 0 1 0 22 6 59:7-59:2
84. MIDImod level 1 x 1 0 2 -99 198 8 60:7-60:0
85. MIDImod source 2 x 1 1 0 0 10 4 61:3-61:0
86. MIDImod destination 2 x 1 1 1 0 22 6 62:1-61:4
87. MIDImod level 2 x 1 1 2 -99 198 8 63:1-62:2
88. Spare 63:7-63:2
* This parameter is stored as 7 bit 2's compliment, with 0 to 6 representing the positive values, and 127 to 122
representing -1 to -6, respectively.
8.20 QS7/QS8//QSR Sys-Ex
The Sys-Ex documentation was not available for these units as of this manual release. In
most cases, the QS6 Sys-Ex will be the same. Known exceptions are in accessing PCMCIA Card
slot 2 and aux audio outputs. This information will be included in future releases of this manual.

Alesis QS Series Specifications

General

Multitimbral	16 parts
Oscillators	Sample-based
Effects	Reverb, Chorus, Delay, EQ, Distortion
Display	LCD
MIDI	In, Out, Thru
Memory	User Programs
Outputs	Stereo
Weight	11 kg
