OPERATING INSTRUCTIONS
22 of 38
www.alfalaval.com
7.2.2 General Operating procedure:
7.2.2.1 Operation of valves:
Pull the handles outwards while rotating them.
When valve V05 is in a position between “Open valve” and “Closed valve”, the flow is
reduced. To operate this valve, turn the handle and then rotate it.
This unit is supplied with a valves arrangement.
It is essential that the
 Lower heat exchanger port is connected to hose S03
 Upper heat exchanger port to hose S02
Refer to P&I diagram in technical dossier, section 3.
