16
Drawing/Parts list
Parts list
SPC-2
Item Qty. Denomination
1 1 Valve body
2 1 Valve plug
31Clamp
4 1 Lip seal kit
4aD 1 Lip seal
4b 1 Plate
1 Plate for FEP seal
4cD 1 Seal ring
1 Seal ring for FEP seal
4d 1 Support ring for FEP seal
4eD 1 O-ring for FEP seal
5 1 Bonnet
6D 1 Bearing
7 1 Valve plug adjuster
8 1 Lock nut
9 1 Clamp fitting
10 1 Striking nut
11 1 Actuator
D : Service kits - EPDM, NBR, FPM
(See Spare Parts List)
The drawing and the parts list include all items. The items are identical with the items in the Spare
Parts List.
When ordering spare parts, please use the Spare
Parts List!
