17
Exploded drawing
This page shows an exploded drawing of SPC-2.
NO = Normally open.
NC = Normally closed.
The drawing includes all items of the valve.
They are identical with the items in the Spare Parts
List
Parts for FEP seal
Drawing/Parts list
