6 Control Cabinet
6.1.3 Adjustable parameters
In manual mode, P6, all parameters can be
adjusted. In auto modes, P1-5, it is possible to
adjust the counter pressure.
Parameter Interval
Comments
Counter pressure
Min. 55 kPa
Too high counter pressure (recommended
60 – 90 kPa) causes the separator to
overflow in the water outlet. Too high flow
might cause overflow, pump cavitation or
problem to regulate the counter pressure.
Flow
Max. 200 l/h Too low flow (recommended 80 – 120 l/h)
makes it impossible to reach min. counter
pressure.
Heater temperature
0-65 °C
6.2 Alarm light pattern
Off - In STOP when separator is in standstill
- In PRODUCTION
Steady shine - During START
- If an active alarm that has been acknow
ledged
exists
- Dur ing STOP as long as separator is n
ot in
standstill
Blinking (0.5s on, 0.5s off)
- When feed pump speed is boosted (Startup
speed)
- If an unacknowledged alarm exists
Flashing (0.2s on, 2s off)
- If system is in STAN DB
Y and no alarm is active
32
