5 Working principle of the separator
5.4 Changing operation mode
When changing operating mode from clarifier to
purifier, or vice versa, proceed as follows:
1. Dismantle the separator in the same way as
when cleaning the bowl, see 9.4.2 Cleaning of
bowl on page 58.
2. Remove the level r ing, O-ring, lower part of
paring chamber and the sleeve with wings.
G05191b1
3. Unscrew the centre screw.
G05191e1
4. Lift out the bowl insert. If it is difficult to get
the insert loose from the bowl spindle, remove
the splash guard (the white plastic ring) to get a
better grip on the bowl bottom.
G05191d1
22
