7 Operating instructions
Control of water content
Stop the separator. Move the hose outlet (1) from
the collecting tank to the filler cup (2) and drain
the content (about 1 litre).
Pour over the content to a glass bottle or similar
to check the water content. If water is found,
operate the separator as a purifier.
*
1
2
G1107011
Control of sludg e content
Dismantle the separator and measure the
thickness (A) of the sludge collected on the bowl
wall, see 9.4.2 Cleaning of bowl on page 58. The
thickness should never exceed 10 mm.
Max. recommended cleaning interval is 3 days.
A longer interval can result in a sludge cake that
is hard and difficult to remove. Too long interva
l
can also result in that sludge enters the disc
stack and hinders separation. Oil overflow an
d
vibration can also occur.
When cleaning very contaminated oil, bowl
cleaning every 20 - 30 minutes could be
necessary.
G0907411
A. Max. thickness = 10 mm (corresponds to
0.6 litre)
1. Sludge
36
