Alfa Laval LKB Series User Manual

22
Drawing/Parts list
Item Qty. Denomination
1 2 Valve body half, welding
1a 2 Valve body half, male
2 1 Valve disc
3D 1 Bush
4D 1 Bush
5D 1 Seal ring
6 1 Set of screws and nuts
7 2 Flange
8D 2 Flange seal ring
D: Service Kit - EPDM, Q, FPM
(See Spare Parts List)
The drawings and the parts list include all items. The items are identical with the items in the Spare
Parts list.
When ordering spare parts, please use the Spare
Parts List!
Parts list
LKB/LKB-2/LKB-F
