5 Dimensions
LC
H1
W1
A
L1
B
A = Plate pack length
B = Foot print length
H1 = Height of the insulation
L1 = Length of the insulation
LC = Length of the carrying bar
W1 = Width of the insulation
200003991-1-EN-GB 13
EN
