7 Installation
7.1 Insulation for small units
This section is only valid for insulation intended for small units. See Chapter
Introduction for sizing. The GPHE is totally built in for the small insulations (no
bolts sticking out).
The GPHE is totally built in for the small insulations (no bolts sticking out).
7.1.1
Installation
WARNING Risk of personal injury.
Wear personal protective equipment when handling the insulation panels.
The gasketed plate heat exchanger shown in the illustrations is just an example of a product where
the small insulation is used.
The piping is not shown in the illustrations.
1
Install the gasketed plate heat exchanger and
connect all piping according to separate
documentation and publications.
200003991-1-EN-GB 19
EN
