6 Technical data
Technical data
General
Operating pressure
400 - 700 kPa ( 4-7 ba
r)
Supply air quality
Class 3 ISO 8573-1
Push-in fittings
ø6 mm tube
Ambient temperature (operating)
-10°C to +50°C
Storage temperature (non operating)
-15°C to +60°C
Protection class IP66 and IP67
IEC 60529
Approvals
UL listed UL 61010
CSA listed
Rated: 24V, 39mA
Class 2 input
Environment type 1
C22.2 No. 61010
Communication
Interface
Digital - PNP
EN61131-2
Supply voltage
24 VDC ± 10%
Current consumption - solenoid active
39 mA
Current consumption - solenoid inactive
28 mA
Short circuit and brownout protection
Yes EN61131-2
Solenoid valve
Type of s olenoid
3/2 NC
Number of solenoids 1
Manual override
Yes (Non-locking)
Actuation flow (at 6 bar)
160 l/
min
Exhaust flow (at 6 bar)
140 l/min
Physical data
Materials
Body
Black nylon PA 6 (reinforced)
Light guide
Transparent polyamide
Seals
Nitrile (NBR)
Cable connection
Cable gland PG7 (cable range ø4.0 - ø6.8 mm)
Recommended conductor cross section
0.5 mm
2
(AWG20)
Terminal block connection data
Conductor cross section min.
0.5 mm
2
(AWG20)
Conductor cross section max.
1.5 mm
2
(AWG16)
1
2
