7 Parts list and service kits
Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine
spare parts.
Service kits
Denomination
DN/OD 51
DN 50
Seat ø53.3
DN/OD 63.5
DN/OD 76.1
DN 65/DN 80
Seat ø81.3
#2
DN/OD 101.6
DN 100
Seat ø100.3
#1
DN/OD 101.6
DN 100
Seat ø115.3
DN 125
DN 150
Seat ø115.3
♦
Service kit, EPDM ............................
9611921550 9611921552 9611926334 9611921554 9611926025
♦
Service kit, NBR .............................
9611921556 9611921558 9611926335 9611921560 9611926026
♦
Service kit, FPM ..............................
9611921562 9611921564 9611926336 9611921566 9611926027
♦
Service kit, HNBR ............................
9611921568 9611921570 9611926337 9611921572 9611926028
For mixed size housings, the service kit is determined by the smallest size connection on the valve.
One exception is any housing with 6” connections will always refer to the 6” service kits listed below:
♦
Service kit, EPDM ............................
9611926105 9611926169 9611926374 9611926233
♦
Service kit, NBR .............................
9611926106 9611926170 9611926375 9611926234
♦
Service kit, FPM ..............................
9611926107 9611926171 9611926376 9611926235
♦
Service kit, HNBR ............................
9611926108 9611926172 9611926377 9611926236
Parts marked with
♦ are included in the service kit.
#1 = Serial no. below 1030000 - manufactured before October 1st 2003
#2 = Serial no. above 1030000 - manufactured after October 1st 2003
NOTE!
If different connection size on upper and lower body, except for size 6", it is always the smallest body that determines the service kit.
If clamped valve body an extra O-ring (pos. 52) is required.
If SpiralClean in leakage chamber extra O-rings (2x pos. 39 and 1x pos. 40) is required.
Spare parts for mix size please refer to Configurator in AL Anytime
NOTE!
All FPM service kits are supplied with EPDM seal ring, pos. 74.
107
