6 Technical data
It is important to observe the technical data during installation, operation and maintenance.
Inform the personnel about the technical data.
6.1 Technical data
Unique is remote-controlled by means of compressed air. The valve is a normally closed (NC) valve.
The valve has two independent plug seals, forming a leakage chamber between them under atmospheric pressure during every
working condition. In case of rare accidental leaking of product, this will flow into the leakage chamber and be discharged
through the leakage outlet.
Data
Max. product pressure:
1000 kPa (10 bar) (145 psi)
Min. product pr
essure:
Full vacuum
Recommended min. pressure for SpiralClean: 2bar(29psi)
Temperature range:
-5°C to +125°C (23°F - 257°F) (Depending on rubber quality)
Air pressure:
Max. 800 kPa (8 b
ar) (116 psi)
Products acc. to 2014/68/EC
Category I, Fluids group 1
DN ≥ 125 Fluids group 2
Materials
Product wetted steel parts:
Acid-resistant steel AISI 316L
Other steel parts:
Stainless steel AISI 304
Product wetted parts:
EPDM, HNBR, NBR or FPM
Other seals: CIP seals: EPDM
Actuator seals: NBR
Surface fin
ish:
Internal/external matt (blasted) Ra < 1.6 (64 µ”)
Internal bright (polished) Ra < 0.8 (32 µ”)
Internal/external bright (internal polished) Ra < 0.8 (32 µ”)
Note! The Ra-values are only for the internal surface.
Weight (kg)
DN/OD
DN
Size
38 51 63.5 76.1 101.6 40 50 65 80 100 125 150
Weight (kg) - Basic
13.5
15
24 24 34 13.5
15
24 24 34
44 45
Weight (kg) - SeatClean
13.5
15
24 24 34 13.5
15
24 24 34
47
48
Weight (kg) - High-/UltraClean
14.5 16 27 27 38 14.5 16 27 27 38 51 52
Noise
One metre away from - and 1.6 metre above the exhaust the noise level of a valve actuator will be approimately 77db(A) without
noise damper and approximately 72 db(A) with damper - measured at 7 bars air-pressure.
