5 Maintenance
Maintain the valve/actuator regularly. Study the instructions carefully and pay special attention to the warnings! Always use
Alfa Laval genuine spare parts, and keep spare rubber seals and guide rings in stock. The valve is designed so that internal
leakages do not result in the products becoming mixed. Internal leakage in the valve is externally visible. Check the valve
for smooth operation after service.
Step 4
Never touch the cl
ip assembly or the actuator piston rod if the
actuator is supplied with compressed air (see the warning label).
Air
Moving parts
Recommended spare parts: Service kits
Order service kits from the service kits section - see section 7 Parts list and service kits
Ordering spa
re parts: Contact the Sales Department.
Valve rubber seals
Valve plug seals Valve guide rings
Preventive maintenance
Replace after 12 months(*) Replace after 12 months(*)
Replace when
required
Maintenan
ce after leakage
(leakage normally starts slowly)
Replace after production
cycle
Replace after production
cycle
Planned maintenance - Regular inspection for
leakage and smooth
operation
- Keep a record of the valve
- Use the statistics for
planning of inspections
- Regular inspection for
leakage and smooth
operation
- Keep a record of the valve
- Use the statistics for
planning of inspections
Replace when required
Lubrication When assembling
Klüber Paraliq GTE 703 or
simila
r USDA H1 appr oved
oil/grease (**) (suitable for
EPDM)
When assembling
Klüber Paraliq GTE 703 or
simila
r USDA H1 approved
oil/grease (**) (suitable for
EPDM)
None
NOTE!
Lubricate thread in valve plug parts with Klüber Paste UH1 84-201 or similar.
(*) Depending on working conditions! Please contact Alfa Laval.
(**) All products wetted seals.
