7 Parts list and service kits
Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine
spare parts.
Parts list
Pos. Qty Denomination
11
Upper stem
2
4
Screw
3
1
Air fitting
3.1
1
Air fitting
3.2
1
Air fitting
41
Stop for upper piston
5
1
O-ring, NBR
6
1
Guide ring, Turcite
7
1
O-ring, NBR
8
1
Upper piston
9
1
O-ring, NBR
10
1
Spring assembly
11 1
Distance spacer
12
1
Pin
13
1
Washer
14 1
Spring assembly
15 1
Plug
15.1 1
Plug
17 1
Main piston
18
1
Guide ring, Tur
cite
19
1
O-ring, NBR
20
1
O-ring, NBR
21
1
Bottom
22
1
Guide ring, T
urcite
23
1
O-ring, NBR
24
1
Retaining r
ing
25
1
Cover disk
26
1
O-ring, NB
R
27
1
Inner stem
28
1
O-ring
29
1
Piston rod
30
1
Lower pis
ton
31
1
O-ring, NBR
32
1
Guide ri
ng, Turcite
33
1
O-ring, NBR
34 3 Bolt
35 3 Washer
36 3 Nut
Service kits
Denomination
#2
DN/OD 101.6
DN 100
Seat ø100.3
#2
DN/OD 101.6
DN 100
Seat ø100.3
unbalanced
lower plug
#1
DN/OD 101.6
DN 100
Seat ø115.3
#1
DN/OD 101.6
DN 100
Seat ø115.3
unbalanced
lower plug
DN 125
DN 150
Seat ø115.3
DN 125
DN 150
Seat ø115.3
unbalanced
lower plug
Actuator service kits .......
9611926416 9611926416 9611926416 9611926416 9611926416 9611926416
Parts marked with
areincludedintheservicekit.
#1 = Serial n
o. below 1030000 - manufactured before October 1st 2003
#2 = Serial no. above 1030000 - manufactured after October 1st 2003
44
