7 Parts list and service kits
Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine
spare parts.
Service kits
Denomination
DN/OD 51
DN 50
Seat ø53.3
DN/OD 63.5
DN/OD 76.1
DN 65/DN 80
Seat ø81.3
#2
DN/OD 101.6
DN 100
Seat ø100.3
#1
DN/OD 101.6
DN 100
Seat ø115.3
DN 125
DN 150
Seat ø115.3
♦
Service kit, EPDM ............................
9611921598 9611921599 9611926342 9611921602 9611926033
♦
Service kit, NBR .............................
9611921605 9611921606 9611926343 9611921608 9611926034
♦
Service kit, FPM ..............................
9611921611 9611921612 9611926344 9611921614 9611926035
♦
Service kit, HNBR ............................
9611921617 9611921618 9611926345 9611921620 9611926036
For mixed size housings, the service kit is determined by the smallest size connection on the valve.
One exception is any housing with 6” connections will always refer to the 6” service kits listed below:
♦
Service kit, EPDM ............................
9611926113 9611926177 9611926382 9611926241
♦
Service kit, EPDM ............................
9611926114 9611926178 9611926383 9611926242
♦
Service kit, EPDM ............................
9611926115 9611926179 9611926384 9611926243
♦
Service kit, EPDM ............................
9611926116 9611926180 9611926385 9611926244
Parts marked with
♦ are included in the service kit.
#1 = Serial no. below 1030000 - manufactured before October 1st 2003
#2 = Serial no. above 1030000 - manufactured after October 1st 2003
NOTE!
If different connection size on upper and lower body, except for size 6", it is always the smallest body that determines the service kit.
If clamped valve body an extra O-ring (pos. 52) is required.
If SpiralClean in leakage chamber extra O-rings (2x pos. 39 and 1x pos. 40) is required.
Spare parts for mix size please refer to Configurator in AL Anytime
NOTE!
All FPM service kits are supplied with EPDM seal ring, pos. 74.
59
