7 Parts list and service kits
Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine
spare parts.
Service kits
Denomination
DN/OD 38
DN 40
Seat ø53.3
DN/OD 51
DN 50
Seat ø53.3
DN/OD 63.5
DN/OD 76.1
DN 65/DN 80
Seat ø81.3
#2
DN/OD 101.6
DN 100
Seat ø100.3
#1
DN/OD 101.6
DN 100
Seat ø115.3
DN 125
DN 150
Seat ø115.3
♦
Service kit, EPDM ..........
9611921622 9611921623 9611921624 9611926346 9611921626 9611926037
♦
Service kit, NBR ...........
9611921628 9611921629 9611921630 9611926347 9611921632 9611926038
♦
Service kit, FPM ............
9611921634 9611921635 9611921636 9611926348 9611921638 9611926039
♦
Service kit, HNBR ..........
9611921640 9611921641 9611921642 9611926349 9611921644 9611926040
For mixed size housings, the service kit is determined by the smallest size connection on the valve.
One exception is any housing with 6” connections will always refer to the 6” service kits listed below:
♦
Service kit, EPDM ..........
9611926089 9611926117 9611926181 9611926386 9611926245
♦
Service kit, NBR ...........
9611926090 9611926118 9611926182 9611926387 9611926246
♦
Service kit, FPM ............
9611926091 9611926119 9611926183 9611926388 9611926247
♦
Service kit, HNBR ..........
9611926092 9611926120 9611926184 9611926389 9611926248
Parts marked with
♦ are included in the service kit.
#1 = Serial no. below 1030000 - manufactured before October 1st 2003
#2 = Serial no. above 1030000 - manufactured after October 1st 2003
NOTE!
If different connection size on upper and lower body, except for size 6", it is always the smallest body that determines the service kit.
If clamped valve body an extra O-ring (pos. 52) is required.
If SpiralClean in leakage chamber extra O-rings (2x pos. 39 and 1x pos. 40) is required.
Spare parts for mix size please refer to Configurator in AL Anytime
NOTE!
All FPM service kits are supplied with EPDM seal ring, pos. 74.
63
