7 Parts list and service kits
Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine
spare parts.
Service kits
Denomination
DN/OD 38
DN 40
Seat ø53.3
DN/OD 51
DN 50
Seat ø53.3
DN/OD 63.5
DN/OD 76.1
DN 65/DN 80
Seat ø81.3
#2
DN/OD 101.6
DN 100
Seat ø100.3
#1
DN/OD 101.6
DN 100
Seat ø115.3
DN 125
DN 150
Seat ø115.3
♦
Service kit, EPDM ..........
9611921670 9611921671 9611921672 9611926354 9611921674 9611926045
♦
Service kit, NBR ...........
9611921676 9611921677 9611921678 9611926355 9611921680 9611926046
♦
Service kit, FPM ............
9611921682 9611921683 9611921684 9611926356 9611921686 9611926047
♦
Service kit, HNBR ..........
9611921688 9611921689 9611921690 9611926357 9611921692 9611926048
For mixed size housings, the service kit is determined by the smallest size connection on the valve.
One exception is any housing with 6” connections will always refer to the 6” service kits listed below:
♦
Service kit, EPDM ..........
9611926093 9611926125 9611926189 9611926394 9611926253
♦
Service kit, NBR ...........
9611926094 9611926126 9611926190 9611926395 9611926254
♦
Service kit, FPM ............
9611926095 9611926127 9611926191 9611926396 9611926255
♦
Service kit, HNBR ..........
9611926096 9611926128 9611926192 9611926397 9611926256
Parts marked with
♦ are included in the service kit.
#1 = Serial no. below 1030000 - manufactured before October 1st 2003
#2 = Serial no. above 1030000 - manufactured after October 1st 2003
NOTE!
If different connection size on upper and lower body, except for size 6", it is always the smallest body that determines the service kit.
If clamped valve body an extra O-ring (pos. 52) is required.
If SpiralClean in leakage chamber extra O-rings (2x pos. 39 and 1x pos. 40) is required.
Spare parts for mix size please refer to Configurator in AL Anytime
NOTE!
All FPM service kits are supplied with EPDM seal ring, pos. 74.
71
