7 Parts list and service kits
Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine
spare parts.
Service kits
Denomination
DN/OD 51
DN 50
seat ø53.3
DN/OD 63.5
DN/OD 76.1
DN 65/
DN 80
seat ø81.3
#2
DN/OD 101.6
DN 100
seat ø100.3
#1
DN/OD 101.6
DN 100
seat ø115.3
DN 125
DN 150
seat ø115.3
♦
Service kit, EPDM ............................
9611921767 9611921769 9611926366 9611921771 9611926061
♦
Service kit, NBR .............................
9611921773 9611921775 9611926367 9611921777 9611926062
♦
Service kit, FPM ..............................
9611921779 9611921781 9611926368 9611921783 9611926063
♦
Service kit, HNBR ............................
9611921785 9611921787 9611926369 9611921789 9611926064
For mixed size housings, the service kit is determined by the smallest size connection on the valve.
One exception is any housing with 6” connections will always refer to the 6” service kits listed below:
♦
Service kit, EPDM ............................
9611926141 9611926205 9611926406 9611926269
♦
Service kit, NBR .............................
9611926142 9611926206 9611926407 9611926270
♦
Service kit, FPM ..............................
9611926143 9611926207 9611926408 9611926271
♦
Service kit, HNBR ............................
9611926144 9611926208 9611926409 9611926272
Parts marked with
♦ are included in the service kit.
#1 = Serial no. below 1030000 - manufactured before October 1st 2003
#2 = Serial no. above 1030000 - manufactured after October 1st 2003
NOTE!
If different connection size on upper and lower body, except for size 6", it is always the smallest body that determines the service kit.
If clamped valve body an extra O-ring (pos. 52) is required.
If SpiralClean in leakage chamber extra O-rings (2x pos. 39 and 1x pos. 40) is required.
Spare parts for mix size please refer to Configurator in AL Anytime
NOTE!
All FPM service kits are supplied with EPDM seal ring, pos. 74.
87
