7 Parts list and service kits
Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine
spare parts.
Service kits
Denomination
DN/OD 38
DN 40
Seat ø53.3
DN/OD 51
DN 50
Seat ø53.3
DN/OD 63.5
DN/OD 76.1
DN 65/DN 80
Seat ø81.3
#2
DN/OD 101.6
DN 100
Seat ø100.3
#1
DN/OD 101.6
DN 100
Seat ø115.3
DN 125
DN 150
Seat ø115.3
♦
Service kit, EPDM ..........
9611921814 9611921815 9611921816 9611926370 9611921818 9611926069
♦
Service kit, NBR ...........
9611921820 9611921821 9611921822 9611926371 9611921824 9611926070
♦
Service kit, FPM ............
9611921826 9611921827 9611921828 9611926372 9611921830 9611926071
♦
Service kit, HNBR ..........
9611921832 9611921833 9611921834 9611926373 9611921836 9611926072
For mixed size housings, the service kit is determined by the smallest size connection on the valve.
One exception is any housing with 6” connections will always refer to the 6” service kits listed below:
♦
Service kit, EPDM ..........
9611926097 9611926149 9611926213 9611926410 9611926277
♦
Service kit, NBR ...........
9611926098 9611926150 9611926214 9611926411 9611926278
♦
Service kit, FPM ............
9611926099 9611926151 9611926215 9611926412 9611926279
♦
Service kit, HNBR ..........
9611926100 9611926152 9611926216 9611926413 9611926280
Parts marked with
♦ areincludedintheservicekits.
#1 = Serial no. below 1030000 - manufactured before October 1st 2003
#2 = Serial no. above 1030000 - manufactured after October 1st 2003
NOTE!
If different connection size on upper and lower body, except for size 6", it is always the smallest body that determines the service kit.
If clamped valve body an extra O-ring (pos. 52) is required.
If SpiralClean in leakage chamber extra O-rings (2x pos. 39 and 1x pos. 40) is required.
Spare parts for mix size please refer to Configurator in AL Anytime
NOTE!
All FPM service kits are supplied with EPDM seal ring, pos. 74.
95
