IMPORTANT NOTICE
The stove normally switches on after about 15 minutes, with a good quality of the pellet fuel and with an ambient
temperature of 11 degrees. If the ambient temperature is lower and the spark plug functions normally, cancellation of
the stove ignition may occur. If this happens, you should switch off the stove by pressing the button 4. Than take
remove and empty the cast burner (figure 14) where the pellets fall and combust. Return the cast burner to its position
in the stove and once again start (restart) the stove by pressing button 4 for few seconds.
• In order to bypass i.e. to circumvent the stage of starting of the stove, press button 6 with a duration of 2
seconds.
This leads directly to the operational stage of the stove. Note: Use this only when the stove is switched on and with
an active flame in the stove.
• In order to change the set ambient temperature (this is the desired temperature of the room where the stove is
located), at any moment press the button 3 and use the buttons 2 and 1 to adjust the temperature indicated on the
lower
display. When the button 3 is pressed, the lower part of the control board indicates the set ambient temperature (the
one you would like to achieve).
• In order to manually set the room ventilation, press button 3. The indication "SET X" is shown on the display
where the flickering letter X represents the speed of the exchanger ventilator, which may be changed by
using the buttons 5 and 6 and which may have the following values:
A = AUTOMTIC speed of the exchanger follows the real indicated energy
1 = SPEED 1 (speed 1)
2 = SPEED 2 (speed 2)
3 = SPEED 3 (speed 3) are all possible manual fan adjustments
4 = SPEED 4 (speed 4)
5 = SPEED 5 (speed 5)
• In order to check the stove temperature, press button 1. The lower display on the control board shows the
temperature, while the upper display shows the number of rotations of the smoke suction motor.
• Switching off of the stove occurs once you press button 4. The upper display shows the message OFF (switched
off)
and the flow of pellet fuel into the firebox is stopped. After cooling, the tangential fan switches off (stops working) and
after 10 minutes from the moment of cooling, the suction device switches off as well. The switching off speed of the
smoke suction device is a parameter which may be set only by an authorized repairman.
NOTE: Even when the stove is cold, switching off of the smoke suction device occurs after about 10 to 15 minutes.
For this reason DO NOT switch off the stove from the main switch (0-1) one the stove is switched off (OFF).
Wait until the switching off cycle is finished, that is, after cooling of the stove as it is previously described.
9.3 PARAMETERS USED BY THE STOVE USER
(Press button 3 to access the parameters)
Every time when you press this button you may get one of the following parameters with the corresponding functions
given here:
Use buttons 1 and 2 to change the value of the parameters
UT01: day in the week. Day 1 … Day 7 or OFF to show that the programming is switched off
UT02: change the current hours
UT03: change of minutes
UT04: button for access to technical parameters (reserved). DO NOT TOUCH. THE PARAMETERS ARE FACTORY
ADJUSTED AND RESERVED FOR EXPERTS AND TECHNICAL STAFF OF THE STOVE MANUFACTURER.
UT05: change of the starting time (program 1) in stages of 10 minutes
UT06: change of the switching off time (program 1) in stages of 10 minutes
UT07: change of program 1, active / inactive, days in the week with the button 2 and going over through the days with
button 1. Confirm and proceed with button 3.
UT08: change of the starting time (program 2) in stages of 10 minutes
UT09: change of the switching off time (program 2) in stages of 10 minutes
UT10: change program 2, active / inactive, days in the week with button 2 and going over through the days with button
1. Confirm and leave the parameters with button 3.
UT11: change of the starting time (program 3) in stages of 10 minutes
UT12: change of the switching off time (program 3) in stages of 10 minutes
UT13: change program 3, active / inactive, days in the week with the button 2 and going over through the days with
button 1. Confirm and proceed with button 3.
UT14: change of the starting time (program 4) in stages of 10 minutes
UT15: change of the switching off time (program 4) in stages of 10 minutes
UT16: change program 4, active / inactive, days in the week with button 2 and going over through the days with button
1. Confirm and leave the parameters with button 3.
NOTE: In order to go to the next parameter, use the button 3 (adjustment), button 1 for increasing and button 2 for
reduction.
NOTE: You can leave the program at any time by pressing button 4.
The stove programming enables that you program the starting and the switching off of the stove four time in one day,
seven days in the week (with the day 1 that indicates the day when the first programming has been performed).
