alfaplam TERM -20 - 0. TECHNICAL DATA

0.TECHNICAL DATA
HEATING POWER WITH GRATE IN LOWER POSITION:
Rated heating power (wood)
22,9 kW
Heating power of solid fuel emission (wood)
8,7 kW
Thermal power of delivered water (wood)
14,2 kW
HEATING POWER WITH GRATE IN UPPER POSITION:
Rated heating power (wood)
16 kW
Heating power of solid fuel emission (wood)
6 kW
Thermal power of delivered water (wood)
10 kW
REQUIRED FLUE DRAFT
15,5 Pa
DIAMETER OF FLUE EXTENSION
150 mm
HEIGHT FROM FLOOR TO AXIS OF FLUE EXTENSION
690 mm
SOLID FUEL DIMENSIONS:
Width
900 mm
Height
850 mm
Depth
600 mm
OVEN DIMENSIONS:
Width
460 mm
Height
260 mm
Depth
440 mm
FIREBOX DIMENSIONS:
Width
265 mm
Height (min./max.)
264/452 mm
Depth
414 mm
OPENING OF FIREBOX DOOR (width/height)
175/200 mm
CONNECTIONS OF DISCHARGE AND RETURN LINE
R1 RS
CONNECTIONS OF THERMO VALVE AND SAFETY VALVE
R1/2 RU
CONNECTIONS OF COOLING PIPES
R1/2 RS
BOILER VOLUME
14 (l)
HEATING VOLUME WITH GRATE IN LOWER POSITION:
280-380m
3
(total)
Heating volume of solid fuel emission
100 -135 m
3
Heating volume of hot water (radiators)
180-230 m
3
HEATING VOLUME WITH GRATE IN UPPER POSITION:
190-250m
3
(total)
Heating volume of solid fuel emission
70-95 m
3
Heating volume of hot water (radiators)
120-155m
3
MAXIMAL OPERATING PRESSURE
1,9 bar
MAXIMAL OPERATING TEMPERATURE
90 C
WEIGHT (gross/net)
186/164 kg
The heating power is shown for stoking dry beech wood with lower heating power Hd=4255W/kg.
DEAR BUYERS!
Thank You for the trust you showed us buying our solid fuel for floor heating. We assure You that You have chosen a quality
and economic product that is a result of many years of experience of this factory in the production of solid fuels and furnaces
for floor heating.
We hope that we fully met Your requirements in terms of design, as well as in terms of the surface of living area that you can
heat.
Please carefully read these instructions before connecting the solid fuel and adhere to every advice provided herein.
-IT IS MANDATORY TO INSTALL A THERMAL DRAIN VALVE TOGETHER WITH THE THERMAL THERMAL PROTECTION OF
THE SO CALLED THERMAL FUSE IN ACCORDANCE WITH THE RECOMMENDATIONS OF THE USER'S MANUAL.
-IT IS MANDATORY TO INSTALL A CONTACT THERMOSTAT IN ORDER TO CONTROL THE CIRCULATION PUMP AT A
MINIMUM RECOMMENDED SET TEMPERATURE OF 57ᵒC.
-IT IS MANDATORY TO USE FIREWOOD WITH A HUMIDITY PERCENTAGE OF LESS THAN 25% OR FIREWOOD THAT HAS
BEEN STORED IN A DRY OPEN SPACE FOR TWO YEARS
-THE MINIMUM INSTALLED POWER OF THE HEATING SYSTEM MUST NOT BE LESS THAN 65% OF THE NOMINAL POWER OF
THE SOLID FUEL AND THE MAXIMUM INSTALLED POWER OF THE HEATING SYSTEM MUST NOT BE MORE THAN 100% OF
THE NOMINAL POWER OF THE SOLID FUEL.
-THE CHIMNEY TO WHICH THE SOLID FUEL IS CONNECTED MUST MEET THE REQUIREMENTS PROVIDED IN THE USER
MANUAL.
-WHEN CONNECTING THE APPLIANCE TO THE CHIMNEY, NEVER USE FLEXIBLE HOSES INSTEAD OF FLUE PIPES.
