Manual
TIMY3 - General
Page 27
11 Technical data
Processor: Siemens C161 with 3.3 V technology
Time reference: 12.8 MHz TCXO or standard quartz
Time resolution: 1/10 000 seconds
Running precision: Temperature compensated quartz oscillator TCXO:
temperature range -25 to 50 °C: ........ +/- 2.5ppm (+/- 0.009 sec/h)
at aging: ............................................ max. +/- 1 ppm per year
at 25°C, calibrated ........................... +/- 0.3 ppm
Program Memory: FLASH memory with 16 MBit
Data Memory: RAM with 4 MBit, approx. 30 000 times
Display: monochrome LCD graphic display 128 x 64 pixels with extended tem-
perature range and backlight
Keypad: silicone keypad, 26 buttons
Connections: DIN-plug for photocell (7)
banana plug pair – start input (5)
banana plug pair – finish input (6)
banana plug pair – display board (4)
D-sub-25 pin (3)
• 9 timing channels
• RS232 (PC-connection)
• display board
• RS485 (network)
• power supply (8 - 22 VDC in / 7.5 - 21 VDC out)
USB (1)
power supply 8 - 22 V DC in (2)
Channel extension: 5 channels per extension, max. 99 channels
Power supply: Internal:
NM-TIMY2 battery pack or
6 x AA-Alkaline 2 Ah (only for TIMY3 XE)
External:
with charger PS12A, PS12 and 12 V battery or 8 -24 VDC
Operating time: Alkaline: without printer about 50 hours
NM-TIMY2: without printer about 60 hours at 20° C
NM-TIMY2: with printer (3 printed lines per minute) about 47 hours at
20° C
Charging: approx. 18 hours
Printer: graphic thermal printer, max. 6 lines per second
Temperature range: TIMY3 W and WP: -20 to 60°C
Dimensions: TIMY3 W: 204 x 91 x 50 mm
TIMY3 WP: 307 x 91 x 65 mm
Weight: TIMY3 W: 450 g (without battery)
TIMY3 WP: 650 g (without battery and paper)
