m 0009 c0 15:44:00,5499 00
m 0010 c1 15:44:00,8182 00
m 0011 c0 15:44:01,0366 00
C 0011 c0 15:44:01,0366 00
n 0014 c0 15:44:01,0366 00
0020 c0 15:44:15,0077 00
0022 c0 15:44:15,5165 00
0023 c1 15:44:15,7847 00
c 0023 c1 15:44:15,7847 00
i 0023 c1 15:44:15,7847 00
0002 c0 15:43:50,1647 00
0005 c1 15:43:51,6464 00
0006 c0 15:43:51,9669 00
0007 c1 15:43:52,2467 00
0008 c0 15:43:52,4579 00
0009 c1 15:43:52,6941 00
0015 c0M 15:43:55,6200 00
0016 c1M 15:43:55,8800 00
0019 c0M 15:43:57,020 00
m 0007 c0 15:43:59,9927 00
12 Interfaces
12.1 RS232 Interface
Output format: 1 start bit, 8 data bit, no parity bit, 1 stop bit
Bit rate: 9 600 baud factory setting
adjustable: 2400, 4800, 9600, 19200, 28800, 38400
Transmission protocol: ASCII
yNNNNxCCCxHH:MM:SS.zhtqxGGRRRR(CR)
y ................................ first sign is blank or info (see below)
x ................................ blank
NNNN ........................ start number, max. 4-digit, any pre-zero is not shown
CCC .......................... channels of timing device
c0 .............................. channel 0 .......... start channel
c0M ........................... channel 0 ......... triggered by keypad <START>
c1 .............................. channel 1 .......... finish channel
c1M ........................... channel 1 .......... triggered by keypad <STOP>
c2 .............................. channel 2
c3 .............................. channel 3
c4 .............................. channel 4
c5 .............................. channel 5
c6 .............................. channel 6
c7 .............................. channel 7
c8 .............................. channel 8
RT ............................. run time
TT ............................. total time
SQ ............................. sequential time (lap time)
kmh ........................... speed measurement (possible displays: km/h, m/s, mph)
HH:MM:SS.zhtq......... time in hours, minutes, seconds and 1/10 000 seconds
GG ............................ group, lap or blank
RRRR ........................ rank (only available in ‘classement’ menu)
(CR) .......................... carriage return
Info – the following figures may be in first position:
x ................................ blank
? ................................ time without valid start number
m ............................... time from memory
c ................................ times deleted (e.g. with CLEAR button)
C ............................... memory time deleted (e.g. with CLEAR button)
d ................................ times deleted due to disqualification
i ................................. manually entered time with <INPUT>
n ................................ enter new start number
Example of a RS 232 interface output (e.g. program backup)
