Manual
TIMY3 - General
Page 9
1.4 Keypad
The TIMY3 has a weather-proof (water-proof) silicone keypad. The keypad is ideal for outdoor
use. The keys are raised and have ideal pressure points. Although the TIMY3 is small in di-
mensions, they are easy to operate.
Control keys: all-purpose keys; the function of each one is always visible
in the display.
START/ON: Key for manual start impulse and to switch on the TIMY3.
STOP/OFF: Key for manual stop impulse and to switch off the TIMY3.
Printer: Key for paper output. If you press the combination
and ,
you open the printer menu.
2nd: This key is always used in combination with a second key (additional
function).
Menu: Key to enter the device menu.
CLR: Key to clear the marked times or to clear the memory.
Cursor: Keys to move the cursor in the display.
+
Beginning of a list
+ End of a list
OK green: Switch on, confirm commands or start inputs
OK red: Switch off, confirm commands or finish inputs
