Algo 8198 - Product Specifications

8198 SIP Ceiling Speaker PoE+
Document 90-00109 Algo Communication Products Ltd (604) 454-3792
2020-09-21 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com
Page 63 www.algosolutions.com
Specifications
Power Input:
Type 2 PoE+ IEEE 802.3at (Max 25.5.W)
Dimensions:
8" (20.5cm) diameter without trim ring
9.8" (24.9cm) with trim ring, Total height 6.9" (17.5cm)
Blind mounts into 8" hole. Clearance requirement of 5.5"
(14.0cm) above ½" (1.27cm) gypsum board ceiling
Mounting:
Ceiling Mounting
Weight:
4.5 lb (2 kg)
SIP:
Multiple extensions for Page or Alerting
Multicast:
Receive or transmit
Audio Codecs:
G.711 A-law, G.711 u-law, G.722, Polycom Group Page
Audio Delay:
1 to 1000 ms selectable for synchronization
Audio Memory:
1 GByte available
Speech Processing:
ALC, filtering, compression
Relay Input:
Normally open or normally closed dry contact supervision.
Algo 1202 CallBox, Algo 1203 Wall Switch, EOL
termination
Relay Input Current
Draw Detection
Thresholds:
Active
Idle
Tamper
Normally Open
>4mA
<4mA
N/A
Normally Open with
Supervison
>20mA
4-20mA
<4mA
Normally Closed
<4mA
>4mA
N/A
Normally Closed with
supervision
4-20mA
>20mA
<4mA
Nominal 12V source, current limited to 40mA
Typical supervision resistor value = 1kOhm
Configuration:
Web interface or provisioning
Provisioning:
TFTP, FTP, HTTP, HTTPS
Supervision:
SNMP
NAT:
STUN, CRLF Keep Alive
Processor:
Linux OS ARM Cortex-A8 32-Bit RISC Processor
Server Redundancy:
Primary, secondary, tertiary
Environmental:
+32 to +104 ºF (0 to + 40 ºC); Dry indoor locations only
Compliance:
RoHS, CE, FCC Class A, CSA/UL (USA & Canada)
