* 64-bit and 128-bit WEP
* CKIP
* TKIP
* AES-CCMP
Bluetooth: Bluetooth 4.1 & Bluetooth 4.1 & Bluetooth 4.2
Video
Table 10. Discrete graphics specifications
Discrete graphics
Controller: External display support: Memory size: Memory type
NVIDIA GeForce RTX 2080: One HDMI port and one DisplayPort: 8 GB: GDDR6
NVIDIA GeForce RTX 2080 Ti: One HDMI port and one DisplayPort: 11 GB: GDDR6
Table 11. Integrated graphics specifictions
Controller: External display support: Memory size: Processor
Intel UHD Graphics 620: One DisplayPort: Shared system memory: 8th Generation Intel Core
i3/i5/i7
NOTE: Use discrete card output for best performance.
Intel UHD Graphics 630: One DisplayPort: Shared system memory: 9th Generation Intel Core
i5k/i7k/i9k
NOTE: Use discrete card output for best performance.
Audio
Table 12. Audio specifications
Description: Values
Type: Integrated 7.1 channel audio with S/PDIF support
Controller: Realtek ALC3861
Internal interface: High-definition audio
External interface: 7.1 channel output, microphone-in, stereo headphones, and headset combo
connector
Storage
Your computer supports one of the following specification:
One U.2 drive and two 2.5-inch hard drives
One M.2 2242/2260/2280 solid-state drive, one 3.5-inch hard drive, and two 2.5-inch hard drives
One 3.5-inch hard drive and two 2.5-inch hard drives
NOTE: The primary drive of your computer varies depending on the storage configuration.
For computers:
with a U.2 drive, the U.2 drive is the primary drive
with an M.2 drive, the M.2 drive is the primary drive.
without both U.2 drive and M.2 drive, the 3.5-inch drive is the primary drive.
Table 13. Storage specifications
Storage type: Interface type: Capacity
Two 2.5-inch hard drives: SATA AHCI 6 Gbps: Up to 2 TB
One 3.5-inch hard drive: SATA AHCI 6 Gbps: Up to 1 TB
Two M.2 2242/2260/2280 solid-state drives:
* SATA AHCI 6 Gbps
