Alienware x15 R1 User Manual

Steps
1. Align the screw hole on the solid-state drive bracket with the screw hole on the palm-rest and keyboard assembly.
2. Replace the screw (M2x4) that secures the solid-state drive bracket to the palm-rest and keyboard assembly.
Next steps
1. Install the
solid-state drive.
2. Install the base cover.
3. Follow the procedure in After working inside your computer.
Fans
Removing the fans
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image(s) indicate the location of the fans and provides a visual representation of the removal procedure.
26

Alienware x15 R1 Specifications

General

Processor	Up to 11th Gen Intel Core i9-11900H
Graphics	Up to NVIDIA GeForce RTX 3080 8GB GDDR6
Display	15.6-inch FHD (1920 x 1080) 165Hz
RAM	Up to 32GB DDR4 3200MHz
Storage	Up to 2TB PCIe M.2 SSD
Operating System	Windows 10 Home, Windows 10 Pro
Battery	6-Cell, 87 WHr Lithium Ion
Weight	2.36 kg (5.2 lbs)
Ports	1 x HDMI 2.1, 3 x USB 3.2 Gen 1 Type-A, 1 x Thunderbolt 4, 1 x MicroSD card reader
Wireless	Killer Wi-Fi 6 AX1650 and Bluetooth 5.2
