The
and the
rear connector panel layout is the same except for
the
and the
. The
has a
pair of Speakon
®
connectors for the amplifier outputs and a country dependent
power input, while the
has a pair of XLR connectors for the balanced line
outputs and a universal power input.
Channel 1 to 6
include XLR microphone and TRS phone jack
line inputs. Channel 7 and 8
each include two line input
pairs on RCA phono and TRS jacks which sum together at the input, as well as
an XLR microphone input. The
present all the console
outputs on TRS jacks including LR, Mono, FB, Aux and AB slave feeds. An
additional low level stereo output on RCA phono jacks is included for recording.
The remaining connectors include the four
and
switch selectable
. An optional rack mounting kit
can be fitted.
