ALLEN & HEATH GLD

GLD User Guide 6 AP8561 iss.3
Standard system 32 in (28 mics), 22 out
24 mics at rack, 4 mics at mixer
Systems
Compact system 16 in (12 mics), 14 out
8 mics at rack, 4 mics at mixer
Expanded system 40 in (36 mics), 26 out
32 mics at racks, 4 mics at mixer
Fully expanded system 48 in (44 mics), 30 out
40 mics at racks, 4 mics at mixer
GLD-80 or GLD-112 x1
GLD-AR2412 x1
Connect to dSNAKE
GLD-80 or GLD-112 x1
GLD-AR84 x1
Connect to EXPANDER
GLD-80 or GLD-112 x1
GLD-AR2412 x1
GLD-AR84 x1
Connect to dSNAKE
GLD-80 or GLD-112 x1
GLD-AR2412 x1
GLD-AR84 x2
Connect to dSNAKE and EXPANDER
GLD mixer only 8 in (4 mics), 10 out
4 mics at mixer
Can use I/O module option for networked audio
