Allen & Heath 35 GS_R24 User Guide
POWER-UP CONFIGURATION MODES
Power the console ON whilst holding down PLAY
MIDI Operation modes
It is possible to set GS-R24 to work in different ways depending on preference and the capability of externally connected
equipment. These modes are primarily concerned with setting up the illumination of the Solo Select switch LEDs so that they
tally entirely from the console function or from external MIDI messages received by the console. The modes can also set a tick
message which is required when translating the GS-R24 default MIDI code into the HUI protocol, change the transport from
MMC to note on/off, and set the console into self test or demo mode.
To Set the configuration mode:
Release PLAY and press one of the following Solo/SEL buttons
SEL switch Mode
1 Default MIDI, Internal tally, press/release = note on/off
2 Default MIDI, Internal tally, press once for note on, press again for note off
3 Default MIDI, External tally, press/release = note on/off
4 Default MIDI, External tally, press once for note on, press again for note off
5 REAPER Mode (Pending Controller plug-in becoming available)
6 Default MIDI, External tally, HUI tick ON. For translating to HUI protocol.
7 US 2400 Emulation
8 Test & Demo mode.
To Set the MIDI Channel number:
Power the console ON whilst holding down REC
Release REC and press one of the following Solo/SEL buttons
SEL switch Mode
1 MIDI channel 1
2 MIDI channel 2
3 MIDI channel 3
4 MIDI channel 4
5 MIDI channel 5
6 MIDI channel 6
7 MIDI channel 7
8 MIDI channel 8
9 MIDI channel 9
10 MIDI channel 10
11 MIDI channel 11
12 MIDI channel 12
13 MIDI channel 13
14 MIDI channel 14
15 MIDI channel 15
16 MIDI channel 16
Press STOP and the configuration mode is set
Press STOP and the MIDI channel number is set
