ALLEN & HEATH GS-R24 User Manual

Allen & Heath 9 GS_R24 User Guide
Noise
Mono ch Mic Pre EIN @ 60dB gain 150R input Z 22-22kHz -128.5dBu
Mix Noise, Aux 1-4 out, sends minimum, masters at unity 22-22kHz -84dBu
Mix Noise, Groups 1-4, 24 channels routed, Ref +4dBu, 22-22kHz -89dB (-85dBu)
Mix Noise, LR out, 0 channels routed, Ref +4dBu, 22-22kHz -97dB (-93dBu)
Mix Noise, LR out, 12 channels routed, Ref +4dBu, 22-22kHz -90dB (-86dBu)
Mono ch Mic Pre EIN @ 30dB gain 150R input Z 22-22kHz -124dBu
Mix Noise, LR out, 24 channels routed, Ref +4dBu, 22-22kHz -89dB (-85dBu)
Power consumption Motorised Fader model 170W Nominal 300W Max
Power consumption non-Motorised Fader model 170W
Weight GS-R24 unpacked/packed 30/38kg
Weight GS-R24m unpacked/packed 32/40kg
GS-R24 SPECIFICATIONS

ALLEN & HEATH GS-R24 Specifications

General

Brand	ALLEN & HEATH
Model	GS-R24
Category	Recording Equipment
Language	English
