ALLEN & HEATH iDR Series User Manual

ALLEN&HEATH iDR training JAN08 Page - 13 - of 49
3.3. Loopback
If the digital audio output of the last unit in a chain is connected to the digital audio input of the first unit
in the chain, any input in the system can be routed to any output in the system.
When looping the
audio, you need to
designate one unit to
be the master.

ALLEN & HEATH iDR Series Specifications

General

EQ Bands	4-band parametric EQ per channel
Word Length	24-bit
Dynamic Range	>110dB
THD+N	<0.005%
Control	Ethernet
Connectivity	Ethernet
Audio Processing	96kHz
Mounting	Rackmount
Faders	None (controlled via external surfaces)
Effects	Reverbs, Delays, Modulations
Sampling Rate	96 kHz
