ALLEN & HEATH iLive Series

iLive Reference Guide – Firmware Part 2 - 105 AP6526-2 iss.4
Specification
System Format
Separate MixRa ck and Surface with control & audio over a single CAT5 ACE™ cable
DSP
64x32 RackExtra DSP mix engine located in MixRack
Audio Network Port A
Local audio to/from Surface - ACE™ up t o 120m CAT5 (depending on cable)*
Audio Network Port B
Network option plug-in cards available - see website for details
Control Network
TCP/IP Ethernet (links to Surface via Port A ACE
TM
), built-in switch
PL-Anet
At MixRack for A&H PL Series remote controllers and GPIO
MIDI
In/Out.Can tun nel between Surface and MixRack via network
USB
x2: Data transfer, archiving and firmware update, external touchscreen, keyboard
V
GA
For co nnecting an external mo nitor to the TouchScreen
Mains Power
Internal, 100-240V.AC, 47 -63Hz, 160 W max per unit
Architecture Input Channels
64x with HPF, Insert, Gate, PEQ, Compressor, Limiter/De-esser, Delay
Output Mixes
32x with Ext-in, Insert, PEQ, 1/3 oct GEQ, Compressor, Limiter, Delay
Mix Types
Any combination of Groups, Auxes, Inte rnal FX, Mains, Matrix (mono or stereo)
Main Mix Types
Mono, LR, LCR, LCRp lus, L RSub, LCRSub, L RM, LCRM, None (monitors)
Mono / Stereo
Chan nels and Mixes may be configured as mono or stereo
Patchbays
Virtual patching of: Inputs, Inserts, FX, Mix Ext in, Outputs, Port B audio channel I/O
Inserts
Inserts assignable on all inputs and mixes, patch to any sockets
FX Engines
8x internal stereo 'RackExtra ' FX racks, each capable of DSP emulations of indu stry classics
FX Patching
Inserted or Send/Retu rn loop. Mo no o r stereo sends, stereo re turns
FX Returns
8x extra 'short' stereo return paths (PEQ) or use IP channe ls (full processing)
Max Sources to Mix (Single-Rack)
72x (64 IP chann els and 8x stereo internal FX returns)
Max Sources to Mix (Dual-Rack)
136x (128 IP channels and 8x stereo internal FX returns)
DCAs
16x can be used as DCA or Mute group s
Other processing
64x Gates, 96x Com pressors, 96x Limiters, 112 x PEQ, 32x GEQ
System Latency
Analogue I N to Analogu e OUT (MixRack) <1.6ms, ACE link is 100us (0.1ms) per hop
ADC
24-bit multi-bit delta sigma, 108 d B dynamic range
DAC
24-bit multi-bit delta sigma, 117 d B dynamic range
Frequency Response
20-20kHz +0/-0.5dB
THD+Noise (analog in to out)
0.0018% (-94dBu) @ +16dBu output (mic pre unity gain)
Residual Output Noise
-9 4dB u ty pi cal
Audio Inputs and Outputs XLR Mic/Line Inputs
Recallab le, Balanced, -15 to +65dBu, 1d B resolution, 25dB pad, +48V
Preamp Performa nce
>4 kΩ, +32dBu max input, Noise EIN (150Ω) -127dB
TRS Jack Line Inputs
+/-24 dB t rim, >6kΩ, +4dBu nominal, +22dBu max
RCA Phono Line Inputs
+/-24 dB t rim, >10kΩ , 0dBu nominal, +18dBu max
XLR Line Outputs
Balanced, Relay protected, <75Ω, +4dBu nominal, +22dBu max
TRS Jack Line Outputs
Balanced, Relay protected, <75Ω, +4dBu nominal, +22dBu max
RCA Phono Line Outputs
Unbalanced, Relay protected, <75Ω, 0dBu nominal, +18dBu max
RCA Phono Digital
2 ch SPDIF I/O. I nput upto 96kHz sampling ra te. Output at 48kHz sampling rate
Audio Connections iDR-16 MixRack
16x XLR mic/line in, 8x XLR line out
iDR-32 MixRack
32x XLR m ic/line in, 16x XLR line o ut
iDR-48 MixRack
48x XLR m ic/line in, 24x XLR line o ut
iDR-64 MixRack
64x XLR m ic/line in, 32x XLR line o ut
iLive-R72 Surface
Inputs 8x [4xTRS, 2xRCA, 1xSPDIF], Outputs 8x [4xTRS, 2xRCA, 1xSPDIF]
iLive-T80 Surface
Inputs 8x [4xTRS, 2xRCA, 1xSPDIF], Outputs 8x [4xTRS, 2xRCA, 1xSPDIF]
iLive-T112 Surface
Inputs 16x [8xTRS, 4xRCA, 2xSPDIF], Outputs 12x [8xTRS, 2xRCA, 1xSPDIF]
Local Monitor
TRS L a nd R available at the Surface
Headphones
MixRack: 1/4" jack. Surface: 1/4" jack and minijack
Control iLive-R72 Surface
12x fade rs, 2 banks (8,4), 6 layers = 72 control strips
iLive-T80 Surface
20x fade rs, 2 banks (12,8), 4 layers = 80 con trol strips
iLive-T112 Surface
28x fade rs, 3 banks (12,8,8), 4 layers = 11 2 control strips
Strip Assign
Assign any strip as Input, FX, Mix master, DCA, engine er's W edge /IEM
TouchScreen
800x600 backlit, colour, touch with on-screen keyboard, data encoder
Processing Strip
Instant access to processing, Illuminated en coders, meters, PFL access
Soft Keys
8x user assignable
Faders
100mm motorised, GEQ fader flip mode
Meters
3 colour, 12 LED meter on every strip, PAFL, proc block and TouchScreen
Edit Functions
Copy, Paste, Reset of processing and mix paramete rs
Monitor Funct ions
PFL/AFL selectable, PAFL tools, Local/Phones outputs, Dual We dge/IEM
Talkback
TB mic with phantom power, assignable to any mix, patching, Latch function
Additional Surface Functions
Freeze in Layers, Alt View, Scree n an d LED dimme r
Other control
MIDI, A&H PL Series remote controllers
iLive Editor software for la ptop
Java-based online/offline editor and live control, connect via TCP/IP network
Memories Libraries
Name and store processing, FX, chan nel parameters and PL device settings
Scenes
250x Store all or selected parameters, editab le tree structure, Recall Safe s
Shows
Stores current settings, preferences, all Scenes, Libraries
User Profiles
Administrator and up to 7 Guest users, Permissions, Password protectable
USB
Transfer and archive Shows and Libraries, USB Show Scene filter
Weights and Dimensions iDR-16 MixRack
3U rack, 482mm (19 ") x 132mm (5.2") x 250m m (10"), 9 kg (19.8lbs)
iDR-32 MixRack
6U rack, 482mm (19 ") x 265mm (10.4") x 250 mm (10"), 12kg (26.4lbs)
iDR-48 MixRack
8U rack, 482mm (19 ") x 353mm (14"") x 250mm (10"), 16kg (35.2 lbs)
iDR-64 MixRack
9U rack, 482mm (19 ") x 397mm (15.6") x 250 mm (10"), 17.5kg (38.5lbs)
iLive-R72 - With Sidetrims
475mm (18.7") x 235mm (9.3") x 540 mm (2 1.2"), 12 kg (26.5lbs)
