ALLEN & HEATH iLive Series Reference Guide

iLive Reference Guide – Firmware Part 2 - 20 AP6526-2 iss.4
Using a SEL key to access DCA Settings
With all TouchScreen keys off press a DCA master strip SEL key to
open its assignment view. Touch the screen buttons to toggle the
assignments on or off. The screen provides an alternative to using
the MIX keys to view and change DCA assignments.
DCAs as MUTE GROUPS - Turn the DCA Fader to Zero dB
option on to configure the DCA group as a Mute group. This keeps
the master fader at the ‘0’ position so it does not affect the group
level. Use the DCA master MUTE key as the Mute group master.
DCA master
Assign from:
Input channels
FX return channels
Group masters
Aux masters
Main mix masters
Matrix masters
MUTE
SEL
MIXMIX
PAFL

ALLEN & HEATH iLive Series Specifications

General

Sampling Rate	48kHz
Type	Digital Mixing System
Faders	Motorized
Ethernet Ports	Yes
Recallable Preamps	Yes
Built-in Rackmount Mixer	No
Weight	Varies by model
FX Engines	8
Remote Control	Yes, via Ethernet
Audio Networking	Dante
EQ	4-band parametric per channel
Dynamics	Compressor, gate on every channel
Effects	Reverb, Delay
Digital Connectivity	MADI
Control Surface Options	Various surface sizes available
Expandability	Yes
Compatibility	Compatible with iLive MixRacks and Surfaces
