Qu-16 User Guide 38 AP9031 iss.2
8.6 Control Setup – Custom Strip
The Custom layer can have any combination of
channel, FX and master strips assigned to its faders.
This lets you arrange the faders you are using for your
show into one layer.
The screen presents an assignment button for each
fader. Touch a button and then turn the screen Rotary
to scroll through the available strips.
Use the Fn key ‘+1’ function to quickly assign strips in
order.
The following strip types may be assigned:
X Unassigned
CH Mono input channels 1-16
ST Stereo input channels 1-3
FX Ret FX returns 1-4
FX Send FX sends 1-2
Mix Mix masters 1-10
LR Main LR master
Select ‘Custom layer only’ if you want to lock out the
two standard layers and let the operator work with just
the Custom layer.
Use the space provided to label the custom strips.
8.7 Control Setup - SoftKeys
Qu features 4 SoftKeys. These are called ‘Soft’
because they can be assigned to different functions by
the user.
Function – Touch the box to open and choose from
the list of available functions. Touch Apply to confirm
the changes.
