ALLEN & HEATH SQ-6 User Manual

 7
MIDI Protocol – ISSUE 1
2. MIDI Faders and Soft Controls
2.1 MIDI faders
The SQ has 32 freely assignable MIDI fader strips. Refer to the SQ Reference
Guide for information on strip assignments.
Each strip sends and responds to the following messages sent on the ‘MIDI
DAW Control Channel’:
MIDI
Strip
Mute Key
Sel Key
PAFL Key
Fader
1
C-1 Note ON/OFF
G#1 Note ON/OFF
E4 Note ON/OFF
CC#0
2
C#-1 Note ON/OFF
A1 Note ON/OFF
F4 Note ON/OFF
CC#1
3
D-1 Note ON/OFF
A#1 Note ON/OFF
F#4 Note ON/OFF
CC#2
4
D#-1 Note ON/OFF
B1 Note ON/OFF
G4 Note ON/OFF
CC#3
5
E-1 Note ON/OFF
C2 Note ON/OFF
G#4 Note ON/OFF
CC#4
6
F-1 Note ON/OFF
C#2 Note ON/OFF
A4 Note ON/OFF
CC#5
7
F#-1 Note ON/OFF
D2 Note ON/OFF
A#4 Note ON/OFF
CC#6
8
G-1 Note ON/OFF
D#2 Note ON/OFF
B4 Note ON/OFF
CC#7
9
G#-1 Note ON/OFF
E2 Note ON/OFF
C5 Note ON/OFF
CC#8
10
A-1 Note ON/OFF
F2 Note ON/OFF
C#5 Note ON/OFF
CC#9
11
A#-1 Note ON/OFF
F#2 Note ON/OFF
D5 Note ON/OFF
CC#10
12
B-1 Note ON/OFF
G2 Note ON/OFF
D#5 Note ON/OFF
CC#11
13
C0 Note ON/OFF
G#2 Note ON/OFF
E5 Note ON/OFF
CC#12
14
C#0 Note ON/OFF
A2 Note ON/OFF
F5 Note ON/OFF
CC#13
15
D0 Note ON/OFF
A#2 Note ON/OFF
F#5 Note ON/OFF
CC#14
16
D#0 Note ON/OFF
B2 Note ON/OFF
G5 Note ON/OFF
CC#15
17
E0 Note ON/OFF
C3 Note ON/OFF
G#5 Note ON/OFF
CC#16
18
F0 Note ON/OFF
C#3 Note ON/OFF
A5 Note ON/OFF
CC#17
19
F#0 Note ON/OFF
D3 Note ON/OFF
A#5 Note ON/OFF
CC#18
20
G0 Note ON/OFF
D#3 Note ON/OFF
B5 Note ON/OFF
CC#19
21
G#0 Note ON/OFF
E3 Note ON/OFF
C6 Note ON/OFF
CC#20
22
A0 Note ON/OFF
F3 Note ON/OFF
C#6 Note ON/OFF
CC#21
23
A#0 Note ON/OFF
F#3 Note ON/OFF
D6 Note ON/OFF
CC#22
24
B0 Note ON/OFF
G3 Note ON/OFF
D#6 Note ON/OFF
CC#23
25
C1 Note ON/OFF
G#3 Note ON/OFF
E6 Note ON/OFF
CC#24
26
C#1 Note ON/OFF
A3 Note ON/OFF
F6 Note ON/OFF
CC#25
27
D1 Note ON/OFF
A#3 Note ON/OFF
F#6 Note ON/OFF
CC#26
28
D#1 Note ON/OFF
B3 Note ON/OFF
G6 Note ON/OFF
CC#27
29
E1 Note ON/OFF
C4 Note ON/OFF
G#6 Note ON/OFF
CC#28
30
F1 Note ON/OFF
C#4 Note ON/OFF
A6 Note ON/OFF
CC#29
31
F#1 Note ON/OFF
D4 Note ON/OFF
A#6 Note ON/OFF
CC#30
32
G1 Note ON/OFF
D#4 Note ON/OFF
B6 Note ON/OFF
CC#31
