SPECIFICATIONS
Operating Levels
Input
Mono channel Mic input (XLR) +6 to –63dBu for nominal (+17dBu in max)
Mono channel Line input (TRS Jack socket) +10 to –26dBu (+30dBu maximum)
Insert point (TRS Jack socket) 0dBu nominal +21dBu maximum
Stereo input (TRS Jack sockets) 0dBu nominal (control = Off to +10dB)
Stereo input (RCA phono sockets) 0dBu nominal (control = Off to +10dB)
Telco channel input (XLR) +10 to –26dBu (+30dBu maximum)
External monitor inputs (RCA phono sockets) 0dBu Nominal
Output
PGM L & R outputs (XLR) +4dBu nominal. +25dBu maximum.
PGM Mono output (RCA phono) 0dBu nominal. +21dBu maximum.
PGM L & R inserts (TRS jack sockets) -2dBu nominal. +21dBu maximum
Aux output (Jack socket) 0dBu nominal. +21dBu maximum.
Mix B outputs (RCA phono sockets) 0dBu nominal. +21dBu maximum.
Audition outputs (RCA phono sockets) 0dBu nominal. +21dBu maximum.
Telco output (XLR) 0dBu nominal. +21dBu maximum.
CRM Speaker outputs (RCA phono sockets) 0dBu nominal. +21dBu maximum.
THD+n
Mic in to PGM L/R Out, 0dB gain, 1kHz, +10dBu out <0.01%
Mic in to PGM Out, 30dB gain, 1kHz, +10dBu out <0.01%
Line in to PGM L/R out 0dB gain, 1kHz, 0dBu out <0.01%
Stereo in to PGM out 0dB gain, 1kHz, +10dBu out <0.01%
USB Audio CODEC (Coder/Decoder)
USB Audio In/Out USB 1.1 compliant 16bit.
Sample Rate 32, 44.1, or 48kHz
Noise
Mic Pre EIN @ max gain 150R input Z 22-22kHz -124dBu
PGM out, PGM fader = 0, 22-22kHz < -100dBu
Audition out, Mix B out = 0, 22-22kHz < -100dBu
Aux out, Mono out = 0, 22-22kHz < -85dBu

ALLEN & HEATH XB-14 MK2 Specifications

General

Brand	ALLEN & HEATH
Model	XB-14 MK2
Category	Music Mixer
Language	English
