ALLEN & HEATH XB-14 MK2 User Manual

Allen & Heath 12 XB-14 MK2 User Guide
Frequency Response
Mic in to PGM L/R Out, 30dB gain +0.5/-1dB 10Hz to 30kHz.
Line in to PGM L/R out 0dB gain +0.5/-1dB 10Hz to 30kHz
Stereo in to PGM L/R out +0.5/-1dB 10Hz to 30kHz
Headroom
Analogue Headroom from nominal (0Vu) Outputs 21dB
USB in & out headroom from nominal (0Vu) 14dB
Analogue Headroom from nominal (0Vu) Mix point 24dB
SPECIFICATIONS
Crosstalk & Attenuation (dB 22-22kHz)
Mono fader attenuation (dB relative to +10dBu) 1kHz/10kHz -95/-95
Mono ON switch attenuation (dB relative to +10dBu) 1kHz/10kHz -95/-95
TELCO fader attenuation (dB relative to +10dBu) 1kHz/10kHz -95/-95
TELCO ON switch attenuation (dB relative to +10dBu) 1kHz/10kHz -95/-95
Stereo fader attenuation (dB relative to +10dBu) 1kHz/10kHz -95/-90
Stereo ON switch attenuation (dB relative to +10dBu) 1kHz/10kHz -95/-95
PGM fader attenuation (dB relative to +10dBu) 1kHz/10kHz -100/-95
TELCO clean-feed isolation from I/P (dB relative to +10dBu) 1kHz/10kHz -55/-40
Stereo separation, L in to PGM R out. dBr 1kHz/10kHz -70/-50
