ALLEN & HEATH ZED-10 User Manual

Allen & Heath 29 ZED-10 User Guide
GROUND
RETURN
SEND
RETURN
OUT
IN
SEND
INSERT
PROCESSOR
LINK RING TO SLEEVE TO UNBALANCE
T
R
S
T
R
S
T
R
S
Insert cable wiring
1=ground
2=hot (+)
3=cold (-)
BALANCED
XLR FEMALE
RCA phono jacks
XLR MALE
2=hot (+)
1=ground
3=cold (-)
RCA PHONO CABLE
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
1=ground
2=hot (+)
3=cold (-)
2=hot (+)
1=ground
3=cold (-)
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
BALANCED
BALANCED
XLR FEMALE
XLR MALE
BALANCED
UNBALANCED
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
UNBALANCED
adapter
UNBALANCED
INSTRUMENT CABLE
TRS JACK CABLE
MIC CABLE
TRS to XLR-F CABLE
TRS to XLR-M CABLE
TO
FROM
INPUT
OUTPUT
2 Outputs to 1 Input
Y-Adapter
No !
1 Output to 2 Inputs
Y-Adapter
Yes
General Wiring Information
WIRING INFORMATION

ALLEN & HEATH ZED-10 Specifications

General

Mic Inputs	4
Line Inputs	6
Aux Sends	2
EQ Bands	3-band EQ with MusiQ
Phantom Power	Yes
Type	Analog Mixer
Channels	10
Inputs - Mic Preamps	4
Inputs - Line	6
USB	Yes
Headphone Output	Yes
Inputs - Other	2 (stereo)
Outputs - Main	XLR
Outputs - Other	RCA, USB
Computer Connectivity	USB
USB Audio Interface	Stereo In/Stereo Out
Weight	3 kg
